• Bright front bumper
• Bright rear bumper w/step pads
• Bright grille
• Halogen headlamps
• Clearance lamps
• Removable tailgate w/color-keyed "Dodge" decal
• Dual bright pwr 6" x 9" exterior mirrors
• Tinted glass
• Variable-speed intermittent windshield wipers
• Corrosion resistant zinc-coated galvanized steel w/anti-chip coating
• Dual rear hinged access doors

• HD vinyl 40/20/40 double split-back bench seat w/rear flip-type bench seat
• Black vinyl floor covering
• 2-spoke steering wheel
• Instrument cluster-inc: 120 MPH speedometer, tachometer
• Electronic AM/FM stereo radio w/cassette-inc: digital clock, (4) speakers
• Dash insulation liner
• Cigar lighter w/pwr outlet
• Day/night rearview mirror
• Passenger assist handle
• Cab back panel stowage
• Cargo lamp

• Driver/front passenger "Next Generation" airbags w/passenger on/off switch
• Pwr 4-wheel anti-lock disc brakes
• Front shoulder belt height adjusters
• Dual note electric horn

5.9L (359) HO I6 CUMMINS TURBO DIESEL ENGINE

• dual 750-amp batteries
• diesel message center (w/low fuel/low oil/water in fuel/wait to start/brakes/anti-lock brake warning lights)
• "Cummins Turbo Diesel" nameplates
• diesel sound insulation on inner dash/cowl/ floor pads
• engine block heater

• Dual rear wheels
• Heated door mirrors
• Rear step bumper
• Bumpers: chrome
• Power door mirrors
• Tachometer
• Voltmeter
• Power steering
• AM/FM radio
• 4 Speakers
• Cassette
• Dual front impact airbags
• ABS brakes
• 4-Wheel Disc Brakes
• Front wheel independent suspension
• Front anti-roll bar
• Passenger cancellable airbag
• Front Center Armrest w/Storage
• Variably intermittent wipers
• 3.54 Axle Ratio

• Electrical
• Cold Cranking Amps @ 0° F (Primary): 750
• Maximum Alternator Capacity (amps): 136
• Maximum Alternator Watts: - TBD -
• Cooling System
• Total Cooling System Capacity (qts): 24.0
• Total Cooling System Capacity (qts): 20.0
• Weight Information
• Gross Axle Wt Rating - Front (lbs): 4500
• Gross Axle Wt Rating - Rear (lbs): 7500
• Curb Weight - Front (lbs): 3062
• Curb Weight - Rear (lbs): 2451
• Gross Vehicle Weight Rating Cap (lbs): 10,500
• Gross Combined Wt Rating (lbs): 20,000
• Gross Combined Wt Rating (lbs): 15,000
• Trailering
• Dead Weight Hitch - Max Trailer Wt. (lbs): 5000
• Dead Weight Hitch - Max Tongue Wt. (lbs): 500
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 10,000
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 1200
• Suspension
• Suspension Type - Front: Coil
• Suspension Type - Rear: Leaf
• Spring Capacity - Front (lbs): 4500
• Spring Capacity - Rear (lbs): 7500
• Axle Type - Rear: Full-Floating
• Axle Capacity - Front (lbs): 4500
• Axle Capacity - Rear (lbs): 7500
• Axle Ratio (:1) - Rear: 3.55
• Shock Absorber Diameter - Front (mm): 35.1
• Shock Absorber Diameter - Rear (mm): 35.1
• Stabilizer Bar Diameter - Front (in): - TBD -
• Brakes
• Brake Type: Pwr
• Brake ABS System: 4-Wheel
• Disc - Front (Yes or ): Yes
• Disc - Rear (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 12.5 x 1.5
• Rear Brake Rotor Diam x Thickness (in): - TBD -
• Tires
• Front Tire Order Code: TSS
• Rear Tire Order Code: TSS
• Spare Tire Order Code: TSS
• Front Tire Size: LT235/85R16E
• Rear Tire Size: LT235/85R16E
• Spare Tire Size: LT235/85R16E
• Front Tire Capacity (lbs): - TBD -
• Rear Tire Capacity (lbs): - TBD -
• Spare Tire Capacity (lbs): - TBD -
• Revolutions/Mile @ 45 mph - Front: - TBD -
• Revolutions/Mile @ 45 mph - Rear: - TBD -
• Revolutions/Mile @ 45 mph - Spare: - TBD -
• Wheels
• Front Wheel Size (in): 16 x 6.0
• Rear Wheel Size (in): 16 x 6.0
• Spare Wheel Size (in): 16 x 6.0
• Front Wheel Material: Steel
• Rear Wheel Material: Steel
• Spare Wheel Material: Steel
• Steering
• Steering Type: Power
• Steering Ratio (:1), On Center: - TBD -
• Steering Ratio (:1), At Lock: - TBD -
• Turning Diameter - Curb to Curb (ft): 51.8
• Turning Diameter - Wall to Wall (ft): - TBD -
• Frame
• Frame Type: Ladder
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 35.0
• Fuel Tank Location: Inboard Frame Rails
• Exterior Dimensions
• Wheelbase (in): 154.7
• Length, Overall w/o rear bumper (in): 240.1
• Width, Max w/o mirrors (in): 93.8
• Height, Overall (in): 77.4
• Overhang, Front (in): 38.0
• Overhang, Rear w/o bumper (in): 47.5
• Front Bumper to Back of Cab (in): 136.9
• Cab to Axle (in): 55.5
• Cab to End of Frame (in): 99.7
• Ground to Top of Load Floor (in): 33.8
• Ground to Top of Frame (in): - TBD -
• Frame Width, Rear (in): - TBD -
• Ground Clearance, Front (in): 15.8
• Ground Clearance, Rear (in): 8.2
• Cargo Area Dimensions
• Cargo Box Length @ Floor (in): 97.5
• Cargo Box Width @ Top, Rear (in): 60.4
• Cargo Box Width @ Floor (in): 64.2
• Cargo Box Width @ Wheelhousings (in): 50.0
• Cargo Box (Area) Height (in): 19.4
• Tailgate Width (in): 60.4
• Cargo Volume (ft³): 70.0
• Ext'd Cab Cargo Volume (ft³): 48.5
• Interior Dimensions
• Passenger Capacity: 6
• Front Head Room (in): 40.2
• Front Leg Room (in): 41.0
• Front Shoulder Room (in): 66.5
• Front Hip Room (in): 63.6
• Second Head Room (in): 39.4
• Second Leg Room (in): 33.2
• Second Shoulder Room (in): 67.1
• Second Hip Room (in): 65.1
• Summary
• Vehicle Name: Dodge Ram 3500
• Body Style: Quad Cab 8'
• Body Code: 155" WB
